NewWeigh E104A
Description
NEWWEIGH E104
Minimum weight, maximum accuracy. Newweigh’s E104 automatic weighers are particularly suitable for weighing very fine products with a low target weight and extremely high accuracy. With the 80 cc weighing pan, weights as low as 0.5 grammes can be achieved, and the load cell with a readout of 0.02 grammes ensures minimal product give-away.
E104A APPLICATIONS
The Newweigh E104 automatic weigher is a high-quality machine designed for all free-flowing bulk materials such as tea, rice, seeds, detergents, fertiliser, cereals, animal feed, plastic granules, pellets, etc.
Salt
Seeds
Beads
Chocolate sprinkles
Discodip
Flaked seeds
ADVANTAGES OF THE E104
The NewWeigh E104 from Laurijsen WeegAutomaten offers a wide range of benefits:
Very high capacity and accuracy
Average weight control
Maintenance-free
Robust and compact design
Short changeover time
Automatic tare
Attractively priced
Easy to clean
35 years’ experience
80 / 200 / 300 cc Weighing bowl capacity
Weighing range 0.5 – 50 grams
Capacity up to 15 wpm per cup
HOW THE NEWWEIGH E104A WORKS
The product is metered from the storage hopper (equipped with a product slide that determines the layer thickness) through a vibrating chute to the weighing pan. The vibration intensity across two stages (coarse and fine) and the weight setting are controlled via a touch-screen and can be saved per programme. All Newweigh automatic weighers feature an automatic control system that optimises itself during the dosing process and responds to any fluctuations in the product feed or composition. This ensures exceptionally high and consistent accuracy, down to as little as 0.1 per cent.
DESIGN
All parts coming into contact with the product are made of 304 stainless steel (2B finish). A version in 316 stainless steel is also available on request. The E104 can be built with multiple heads. A wider chute and a 200CC weighing hopper are also available as options.
